AR33.30-P-0620GZ Remove/Install Front Axle Shafts

AR33.30-P-0620GZ Remove/Install Front Axle Shafts
MODEL 164





Shown on the right side of vehicle with Airmatic (air suspension with level adjustment and Adaptive Damping System ADS), code 489

1 Front axle shaft collar nut
2 Bracket
3 Bracket
4 Cable tie
5 Brake hose
6 Brake hose bracket





Shown on the right side of vehicle with Airmatic (air suspension with level adjustment and Adaptive Damping System ADS), code 489

7 Extraction and insertion tool





Shown on the right side of vehicle with Airmatic (air suspension with level adjustment and Adaptive Damping System ADS), code 489

8 Nut
9 Nut
10 Steering knuckle





Shown on the right side of vehicle with Airmatic (air suspension with level adjustment and Adaptive Damping System ADS), code 489

11 Screw
12 Transverse control arm
13 Front axle shaft


























140 589 00 63 00
Thrust piece





140 589 09 33 00
Puller





210 589 03 43 00
Extraction and insertion tool





601 589 04 33 00
Puller





164 589 01 37 00
Pliers
