Engine Controls/Exhaust - MIL ON/DTCs P013A/P0130/P0400
TSB 10-18-309/27/10
HYBRID - MIL ON DTCS PO13A, P0030, P0130
AND/OR P0400
FORD:
2009-2010 Escape
MERCURY:
2009-2010 Mariner
This article supersedes TSB 09-20-6 to update the vehicle model years, Service Issue, Service Procedure and Service Labor Time Standards.
ISSUE
Some 2009 Escape Hybrid and Mariner Hybrid vehicles may exhibit a malfunction indicator lamp (MIL) with diagnostic trouble codes (DTCs) P013A and/or P0400. Vehicles built on or before 6/24/2009 with DTC P013A may be caused by an exhaust leak at the manifold catalyst flange.
Some 2010 Escape Hybrid and Mariner Hybrid vehicles may exhibit any of the following DTCs; P013A , P0030, and P0130 and/or P0400. An improved calibration is available for these vehicles.
ACTION
Follow the Service Procedure steps to correct the condition.
SERVICE PROCEDURE
Vehicles with a DTC P013A built on or before 6/24/2009 follow Procedure A and B. Vehicles built on or after 6/25/2009 perform Procedure B.
Procedure A
1. Restrict exhaust flow at the tailpipe and inspect for carbon soot/moisture witness marks indicating a leak at the manifold catalyst flange. Misting a soapy water spray solution on the flange while the exhaust is restricted will increase the ability to identify and confirm leaks.
2. Is a leak present?
a. No - Skip to Procedure B.
b. Yes - Proceed to Step 3.
3. Disconnect the intermediate exhaust pipe from the manifold catalyst. Refer to Workshop Manual (WSM), Section 309-00.
4. Inspect the flange for evidence of weld or other material that is raised on the sealing surface and may prevent complete sealing at the joint. If this condition is found, replace the manifold catalyst assembly and both heated oxygen sensors (H025). Refer to WSM 309-00.
5. Proceed to Procedure B.
Procedure B
Reprogram the powertrain control module (PCM) to the latest calibration using IDS release 68.07 and higher or 69.01 and higher. This new calibration is not included in the VCM 2010.9 DVD. Calibration files may also be obtained at the website.
Parts Block
WARRANTY STATUS: Eligible Under Provisions Of New Vehicle Limited Warranty Coverage And Emissions Warranty Coverage
IMPORTANT: Warranty coverage limits/policies are not altered by a TSB. Warranty coverage limits are determined by the identified causal part.
OPERATION DESCRIPTION TIME
101803A 2009-2010 Escape Hybrid, 0.3 Hr.
Mariner Hybrid: Check
DTCs, Reprogram The
PCM (Do Not Use With
Any Other Labor
Operations)
101803B 2009-2010 Escape Hybrid, 1.7 Hrs.
Mariner Hybrid: Check
DTCs, Replace The
Manifold Catalyst
Assembly And Both HO2S
Sensors, Then Reprogram
The PCM (Do Not Use
With Any Other Labor
Operations)
DEALER CODING
CONDITION
BASIC PART NO. CODE
5G232 04
