Cylinder Head Tightening Specifications


























Using a 10 mm hex wrench and a torque wrench, tighten the bolts in two or three cycles to 105-115 Nm (76-83 ft. lbs.) in the order shown in the illustration.

NOTE: Install the head bolt washers as shown with shear droop upward.







Torque Sequence:
