ABS/TCS - M-ASTC-ECU Initialization Revision
No: TSB-03-35-004DATE: December, 2003
MODEL: 2003 Montero
SUBJECT
GM-ASTC-ECU INITIALIZATION PROCEDURES
- SERVICE MANUAL REVISION
PURPOSE
The initialization procedure for the Mitsubishi Active Skid and Traction Control ECU (M-ASTC-ECU) is incorrectly described in the following service manual page. Whenever installing a new M-ASTC-ECU. the initialization procedure must be performed in order for the ECU to learn the transfer case switches and steering angle in its memory.
Write the TSB revision number of this bulletin in the "TSB Revision" box at the bottom of the affected service manual page.
AFFECTED VEHICLES
2003 Montero
AFFECTED SERVICE MANUAL
2003 Montero, Volume 3, page 36C-206
