Valve Guide





Valve stem to valve guide clearance
Intake
Standard value 0.02 - 0.05 mm (0.0008 - 0.0019 inch)
Limit 0.10 mm (0.003 inch)
Exhaust
Standard value 0.04 - 0.07 mm (0.0016 - 0.0027 inch)
Limit 0.15 mm (0.005 inch)
