Intake Manifold

Intake manifold plenum 22 ± 1 Nm (16 ± 1 ft lb)

Intake manifold





1. Tighten left bank 6.5 ± 1.5 Nm (58 ± 13 in-lb).
2. Tighten right bank 22 ± 1 Nm (16 ± 1 ft-lb)
3. Tighten left bank 22 ± 1 Nm (16 ± 1 ft-lb)
4. Tighten right bank and left bank again in that order 22 ± 1 Nm (16 ± 1 ft-lb)

Service Specification:

Throttle body 23 ± 6 Nm (17 ± 4 ft lb)
