Operation CHARM
: Car repair manuals for everyone.
Home
>>
Mitsubishi
>>
2012
>>
Outlander AWD V6-3.0L (6B31)
>>
Repair and Diagnosis
>>
Transmission and Drivetrain
>>
Automatic Transmission/Transaxle
>>
Shift Interlock
>>
Diagrams
>>
Electrical Diagrams
Electrical Diagrams
SHIFT LOCK MECHANISM
