Operation CHARM
: Car repair manuals for everyone.
Home
>>
Nissan-Datsun
>>
2009
>>
Frontier 4WD V6-4.0L (VQ40DE)
>>
Repair and Diagnosis
>>
Specifications
>>
Mechanical Specifications
>>
Automatic Transmission/Transaxle
>>
System Specifications
>>
Flex Plate
Flex Plate
Drive Plate
Tighten bolts crosswise over several times.
