Coupe

Door Lock At Handle:

Remove or Disconnect

1. Lock module.
2. All rods attached to lock.
3. Lock from lock module by bending three tabs outward.
4. Electrical connector from module to door passive safety belt switch.
5. Lock.

Install or Connect

1. Electrical connector to passive safety belt switch from module.
2. Lock to lock module by bending three tabs inward.
3. All rods disconnected in step 2 of removal procedure.
4. Lock module.
