Impact Sensor: Service and Repair



Note The front sensors are positioned on left and right in the driver and front-passenger footwells at the top on the wheelhouse wall. The installation position is fixed by the method of mounting.

1. Disconnect battery and cover over pole/battery.



2. Take apart plug connector.



3. Loosen rip nuts with special tool P 9259.

Note Use 1/4 inch inside hexagon for tightening the rip nuts. Use specified washers. The mounting points on the body must be bare down to the metal.
