110 Engine Speed Sensor Signal - Open Circuit

P0336

110 Engine Speed Sensor Signal - Open Circuit

Diagnosis conditions
- Engine running

Possible fault cause
- Corrosion in the connector
- Open circuit or short circuit in the wiring harness
- Rpm/crankshaft position sensor faulty.
- DME control module faulty

Affected terminals
III/32, III/45 and III/46

Diagnosis/troubleshooting
