Heated Seat, Left-Hand Front, Inoperative

Heated Seat, Left-hand Front, Inoperative







Fault symptom

Heated seat, left-hand front, inoperative.

Conditions

Seat heating activated.
^ ACC

No DTCs stored with the fault symptom in question.
Seat heating lower than 20 degrees C.
Outside temperature lower than 15 degrees C.

Diagnostic help

Test value:
Seat Temperature Left
Seat Temperature Sensor Left
Ambient Temperature, Filtered
Seat Heating Left

Activate:
Seat Heating Left
(See also description of readings/activations in diagnostic tool)
