49. Oil Pickup Tube Installation
OIL PICKUP TUBE (UNIT REPAIR)INSTALLATION
1. Install new oil pickup tube O-ring seal.
2. Install pickup tube.
3. Install oil pickup tube bolts.
Torque:
Oil Pickup Tube Bolts: 8 N.m (71 inch lbs.)
