71. 3RD Clutch Shaft 3RD Clutch Housing Disassemble

3rd Clutch Shaft 3rd Clutch Housing Disassemble

- Tools Required
- J 21420-2 Plate
- J 23327 Spring Compressor
- J 28585 Snap Ring Remover
- J 45124 Adjustable Bridge





1. Using J 28585, remove the 3rd clutch, backing plate retaining ring (810) from the 3rd clutch housing assembly (831).





2. Remove the following components from the 3rd clutch housing (831):
- 3rd clutch, selective backing plate (811)
- 3rd clutch fiber plates (812)
- 3rd clutch steel plates (813)
- 3rd clutch belleville plate (817)






Important: Do not place the end of the special tool over an area of the spring retainer cap that is unsupported by the clutch return spring.

3. Install the J 45124 on the 3rd clutch housing (821). Ensure that J 45124 is adjusted to have full contact with the 3rd clutch piston return spring cap (815).





4. Using J 23327 (1), J 45124 (2) and J 21420-2 (3), compress the 3rd clutch piston return spring (816).





5. Using snap ring pliers, remove the 3rd clutch piston, return spring cup, retaining ring (814).





6. Remove the tools.
7. Remove the 3rd clutch piston, return spring cup, retaining ring (814).
8. Remove the 3rd clutch piston, return spring cup (815).
9. Remove the 3rd clutch piston, return spring (816).





10. Install the 3rd clutch housing (831) onto the 3rd clutch shaft (823).

Caution: When you use compressed air in order to clear fluid passages and to dry parts, always aim the air pressure away from face and eyes. Always wear adequate eye protection in order to avoid injury from dirt and debris that may adhere to parts.

11. Apply compressed air to the 3rd clutch piston fluid apply port located in the 3rd clutch shaft in order to remove the piston.





12. Remove the following components from the 3rd clutch piston (818):
- 3rd clutch piston, outer O-ring seal (819)
- 3rd clutch piston, inner O-ring seal (820)
