Rear Shelf: Service and Repair
REAR SHELF TRIMREMOVAL 1.
Remove high-mounted stop light.
2.
Remove rear seat backrest.
3.
Remove inner seat belt RH, then disconnect inner seat belt RH (A) and outer seat belt center (B).
4.
Detach
rear shelf trim through each rear outer seat belt from slits (A) and hole (B) of rear shelf trim.
INSTALLATIONInstall in the reverse order of removal.
