Fog/Driving Lamp: Service and Repair
Front Fog Light AssemblyREMOVAL 1.
Disconnect the ground cable from the battery.
2.
Disengage the three clips, and then turn over the lower mud guard.
3.
Disconnect the harness connector.
4.
Remove the two mounting bolts, and pull and detach the fog light assembly.
INSTALLATIONInstall in the reverse order of removal.
Tightening torque: 7.5 N.m (0.76 kgf.m, 5.5 ft.lb)
