Diagnostic Procedure For Sensors
Diagnostic Procedure for SensorsAMBIENT SENSOR
TROUBLE SYMPTOM:
- Ambient temperature is falsely recognized as 15.2 °C, and the compartment temperature is adjusted.
- DTC "22" Faulty ambient sensor, or communication failure is detected.
Trouble causes:
- Ambient sensor failure
- Ambient sensor circuit failure
- CAN communication circuit failure
WIRING DIAGRAM:
