Flywheel/Drive Plate Inspection

Flywheel/Drive Plate Inspection
Reference: Main Bearings, Crankshaft and Cylinder Block Removal and Installation

Visual Inspection
^ Check ring gear of flywheel for M/T model or drive plate for CVT model, for crack, wear or any damage.
If defective condition is found, replace flywheel for M/T model or drive plate for CVT model.

Flywheel/Drive Plate Face Runout
^ Check flywheel for M/T model or drive plate for CVT model for runout using dial gauge and "V" blocks. If measured runout exceeds its limit, replace flywheel for M/T model or drive plate for CVT model.

Flywheel/drive plate face runout.
Limit: 0.2 mm (0.0078 in.)
