Control Assembly Switches
Control Assembly Switches
SWITCH REMOVAL
REMOVE DEFROSTER MODE SWITCH
a.
Release the connector clamp.
b.
Remove the screw and switch.
SWITCH INSTALLATION
Installation is in the reverse order of removal.
