Front Seat (Manual Seat For TMC Made)
DISASSEMBLY1. REMOVE FRONT SEAT
a. Using a screwdriver, remove the seat track outer cover.
HINT: Tape the screwdriver tip before use.
b. Remove the 4 bolts.
c. w/ Side airbag assembly:
Disconnect the connector.
d. Remove the front seat.
NOTE: Be careful not to damage the body.
2. REMOVE RELEASE HANDLE
3. REMOVE FRONT SEAT CUSHION SHIELD
4. w/ Vertical seat adjuster:
REMOVE VERTICAL ADJUSTER KNOB
5. REMOVE FRONT SEAT CUSHION LOWER SHIELD
6. REMOVE SEAT CUSHION INNER SHIELD
7. w/ Lumbar support:
REMOVE LUMBAR SUPPORT LEVER
8. REMOVE HEADREST
9. REMOVE FRONT SEAT INNER BELT
10. REMOVE SEATBACK ASSEMBLY
a. w/ Side airbag assembly:
Remove the side airbag wire harness after removing clips.
b. Remove the bolts and seatback assembly.
11. REMOVE SEATBACK COVER
a. Remove the hog rings.
b. w/ Side airbag assembly:
Remove the hook from the seatback frame.
c. Remove the headrest supports.
d. Remove the seatback frame from the seatback cover with pad.
e. Remove the seatback cover from the seatback pad.
12. REMOVE SEAT CUSHION ASSEMBLY
Remove the 4 bolts and seat cushion assembly from the seat adjuster.
13. REMOVE SEAT CUSHION COVER
a. Remove the seat cushion frame.
b. Remove the seat cushion cover from the seat cushion pad.
14. REMOVE SEAT TRACK ADJUSTING HANDLE
Remove the seat track handle.
15. REMOVE FRONT SEAT OUTER ADJUSTER
Remove the E-ring and front seat outer adjuster from the front seat inner truck with upper track.
REASSEMBLY
1. w/ Vertical seat adjuster:
INSTALL FRONT SEAT OUTER ADJUSTER
Install front seat outer adjuster to front seat inner adjuster with E-ring, nuts and bolts.
2. w/o Vertical seat adjuster:
INSTALL FRONT SEAT OUTER AND INNER ADJUSTER
Install the adjusters to the seat cushion frame.
3. INSTALL SEAT TRACK ADJUSTING HANDLE
Install the seat track adjusting handle.
4. w/ Vertical seat adjuster:
INSTALL SEAT CUSHION COVER
a. Install the seat cushion cover to seat cushion pad.
b. Install the seat cushion cover with pad to the seat cushion frame.
5. INSTALL SEAT CUSHION ASSEMBLY
Install the seat cushion assembly with 4 bolts to the seat adjuster.
HINT: Tighten the 4 bolts temporarily, then from the bolts on the rear side tighten completely.
Torque: 18 N.m (185 kgf.cm, 13 ft.lbf)
6. INSTALL SEATBACK COVER
a. Install the seatback cover to the seatback pad.
b. Install the seatback cover with pad to the seatback frame.
c. Install the headrest supports.
d. w/ Side airbag assembly:
Hang the hook on to the seatback frame.
CAUTION: Take care to hung the hook securely. Otherwise the seat cover slides, it might cause incorrect deploying.
7. INSTALL SEATBACK ASSEMBLY
a. Install the seatback assembly with bolts.
Torque: 18 N.m (185 kgf.cm, 13 ft.lbf)
b. Install new hog rings.
HINT: When installing hog ring, take care to prevent wrinkles as much as possible.
c. w/ Side airbag assembly:
Securely fix the side airbag wire harness to seat cushion and seatback by clips.
8. INSTALL FRONT SEAT INNER BELT
9. INSTALL HEADREST
10. w/ Lumbar support:
INSTALL LUMBAR SUPPORT LEVER
11. INSTALL SEAT CUSHION INNER SHIELD
12. INSTALL FRONT SEAT CUSHION SHIELD
13. w/Vertical seat adjuster:
INSTALL VERTICAL ADJUSTER KNOB
14. INSTALL FRONT SEAT CUSHION LOWER SHIELD
15. INSTALL RELEASE LEVER
16. INSPECT RECLINING LOCK POSITION AND SLIDING LOCK POSITION SLIPPING OFF
a. When reclining the seat, inspect that the outer and inner tracks are released at the same time.
HINT: When the reclining lock positions slip off, disassemble the seat to adjust the position.
b. When sliding the seat, inspect that the outer and inner tracks are locked at the same time.
HINT: When sliding lock positions slip off, loosen the bolts to adjust the position.
17. INSTALL FRONT SEAT
a. Slide the front seat to the most front position.
NOTE: Make sure that seat adjuster locks.
b. Without holding the seat track handle, mount the seat to the vehicle.
HINT: If holding the seat track handle, the adjusted most front positions slip off.
c. Tighten the bolts on the rear side temporarily, from the bolt on the inner side tighten completely.
Torque: 37 N.m (375 kgf.cm, 27 ft.lbf)
d. Slide the seat to the most rear position to install the bolts on the front side.
Torque: 37 N.m (375 kgf.cm, 27 ft.lbf)
