Clearing Trouble Codes

CLEARING DIAGNOSTIC TROUBLE CODES

NOTE: This is the only information provided by the manufacturer for Clearing Diagnostic Trouble Codes for this system.




Clear the DTC.
1. Using SST, connect terminals Tc and E1 of DLC1.
SST 09843-18020

2. Turn the ignition switch ON.
3. Clear the DTC stored in ECU by depressing the brake pedal 8 or more times within 5 seconds.
4. Check that the warning light shows the normal code.
5. Remove the SST from the terminals of DLC1.
SST 09843-18020
