Back-Up Power Source Circuit

BACK-UP POWER SOURCE CIRCUIT

CIRCUIT DESCRIPTION
This is the back-up power source circuit for the A/C amplifier. Power is supplied even when turning the ignition switch off and is used for diagnostic trouble code memory, etc.
