Timing Belt Tensioner

Timing Belt Tensioner





Temporarily install the tensioner with the 2 bolts. Alternately tighten the 2 bolts.
Torque 27 Nm (280 kgf-cm, 20 ft. lbs.)

NOTICE: Be sure to tighten the bolts equally. Installing the tensioner at an angle may cause failure of its proper operation.
