Canada - Fuel System - MIL ON/DTC P1423 Set

Bulletin
TSB3306

Issue Date
December 18, 2009

Market
Canada

Title
MIL "ON" DTC P1423

Component
FUEL

Models
'07-'09 Camry HV

INTRODUCTION:
Some 2007 - 2009 model year Camry HV vehicles may exhibit a MIL "ON" condition with Diagnostic Trouble Code (DTC) P1423, or a fuel cap binding upon installation or removal. Use the following repair procedure to diagnose and repair this condition.






APPLICABILITY:






WARRANTY INFORMATION:






PARTS INFORMATION:






REQUIRED TOOLS & EQUIPMENT:

NOTE:
Additional Techstream units may be ordered by completing the order form on ETAS and faxing it to (416) 431-8342.


REPAIR PROCEDURE:
1. Using ETAS Techstream, check for stored DTCs.
2. Verify DTC P1423 is present.

NOTE:
If there are any codes present other than P1423, this TSB does NOT apply. Refer to the appropriate Repair Manual for diagnosis.

3. Check the fuel cap condition.
Does the fuel cap bind while installing or removing?
- YES - Continue to step 4.
- NO - Refer to the Repair Manual within E-TAS / TIS library:

- Division: Toyota
- Model: Camry HV
- Year: 2007/ 2008/ 2009
- Service Category: Engine/Hybrid System
- Section: Engine Control
- Keyword: 2AZ-FXE Engine Control System: SFI: P1422, P1423: Fuel Tank Small Leak

NOTE:
While installing the cap use light pressure and only turn until the fuel cap clicks one time.

4. Replace the fuel cap and fuel neck assembly.
5. After the repair is complete, perform the Automatic EVAP System Check again to confirm there are NO pending DTC(s) and the system is normal.

NOTE:
Issue of this Technical Service Bulletin is to ensure that proper repair information is available. IT DOES NOT CONSTITUTE AN AUTHORIZATION FOR REPAIR. Normal provisions of the formal warranty policy, as applicable, will apply.
