Reassembly

AIR CONDITIONING: INTEGRATION CONTROL AND PANEL: REASSEMBLY

REASSEMBLY

1. INSTALL AIR CONDITIONER AMPLIFIER ASSEMBLY





(a) Remove the air conditioner amplifier assembly.
(b) Engage the lock of the connector and connect the cable.





(c) Engage the 2 claws and install the rear panel.
(d) Install the 3 screws.
