Removal

EXTERIOR: REAR BUMPER: REMOVAL

1. REMOVE REAR BUMPER ASSEMBLY

(a) Put protective tape around the rear bumper assembly.





(b) Remove the 5 clips, 8 screws and 2 bolts.





(c) Disengage the 8 claws and disconnect the rear bumper assembly.





HINT
Use the same procedure for the RH side and LH side.

(d) Remove the rear bumper assembly.
