Yaris Sedan L4-1.5L (1NZ-FE)
>>
Repair and Diagnosis
>>
Specifications
>>
Mechanical Specifications
>>
Differential Assembly
>>
Torque Specifications
Torque Specifications
SPECIFICATIONS: AXLE AND DIFFERENTIAL (for Sedan): TORQUE SPECIFICATIONS
