With Multi-Function Indicator

With Multi-function indicator, Instrument cluster, assembly






1. Instrument cluster housing
2. Hall speed sensor contact plate
3. Speedometer cable cover
4. Printed circuit
5. Warning lights, right
6. Hall speed sensor
7. Tachometer with oil pressure warning control unfit
8. Speedometer
9. Instrument cluster cover
10. Fuel gauge
11. Multi-function Indicator (MFI)
12. Coolant temperature gauge and low coolant level Indicator
13. Voltage stabilizer
14. Multi-function Indicator (MFI) vacuum sensor
15. Warning lights, left
16. Bulbs and holders
