Headlamp: Service Precautions

Headlights With High Intensity Gas Discharge (HID) Lamps


WARNING!
- HIGH VOLTAGE!
- Always disconnect battery Ground (GND) strap prior to servicing any parts of the HID lamp system marked with the yellow "HIGH VOLTAGE!" symbol.
- After disconnecting battery, briefly turn headlights on and off in order discharge any residual Voltage.

NOTE:
- When removing and installing parking light and high beam bulbs, always remove complete headlight assembly from vehicle.
- HID lamp system has On Board Diagnostic (OBD) capabilities
