Interior/Reading Light Assembly, Removing and Installing
Interior/reading Light Assembly, Removing And Installing
Removing
- Carefully pry lens from interior light -1- and remove.
- Remove screws -2-.
- Pry out hooks -B- with screwdriver and then remove interior light assembly -3- from headliner.
- Disconnect both electrical connections -4- and -5-.
Installing:
- Connect both electrical connections -4- and -5-.
- Insert interior light assembly -3- in at -A- and then clip opposite side in at -B-.
- Install screws -2-.
- Clip in interior light lens -1-.
