External Audio Source Connection (R199)

External Audio Source Connection (R199)

• Familiarity with the function and operation is essential in the event of customer concerns. Refer to the Owner's Manual.

• Use the Vehicle diagnostic tester for servicing or Fault Finding.

• Check the radio, clock and Convenience System after the battery has been connected. Refer to and the Owner's Manual.

Installed location external audio source connection (R199)





The external audio source connection - 1 - is installed in the front cover (center console).

Component location external audio source connection (R199) on the RNS 315





The external audio source connection - 1 - is inside the center console storage compartment. It is located on the right side of the front trim at the bottom.

The external audio source connection works with the radio/radio-navigation system that has an "AUX".

The audio signals from and MP3 player or a portable CD/cassette player can be played in the radio/RNS using an adapter cable connected to the external audio source connection. These will then be transmitted through the speaker system.

Further information, refer to the Owner's Manual.

Overview, refer to => [ Radio and Radio/Navigation Overview ] Radio and Radio/Navigation Overview.
