Camber

Fig. 1 Adjusting Camber:

1. Bounce vehicle up and down several times to set control arms in normal position.
2. Loosen upper strut attaching nuts.
3. Adjust camber using adjustment tool No. 5038, Fig. 1.
4. Tighten strut attaching nuts, then recheck caster angle.
