Air Bag: Locations

Warning And Information Decals Inside Car




On windshield
Decal on front windshield combined with SRS decal. Decal indicates whether car is equipped with SIPS bag.




Driver's side instrument panel
Decal on side of instrument panel on driver's side.

Use only Volvo-approved upholstery covers; other upholstery covers can impair system function. Do not mount any accessories near SIPS bag in seat back. Do not apply force to side of seat. For further information, see owner's manual.




On sensor housing (below seat pocket)
Warning decal at sensor unit. Color orange.

Decal refers to owner's manual for further information.




On driver's side B-post
SRS decal on driver's side B-post has space on lower portion for SIPS-bag decal. Two small decals indicating inspection date of left and right SIPS bag respectively are placed here.




Other labels
Seat pocket is marked with SIPS-bag symbol.
