A/C Signal: Service and Repair

Replacing The Air Conditioning (A/C) System Pressure Sensor

Removing the air conditioning (A/C) system pressure sensor
Drain the air conditioning (A/C) system.

Note: Clean the area around the sensor.





- Remove the battery clamp if necessary.
- Disconnect the connector.
- Remove the sensor.

Installing the air conditioning (A/C) system pressure sensor





- Use a new sealing ring. Lubricate the sealing ring with compressor oil.
- Install the temperature sensor. Tighten the temperature sensor. Tightening torque 18 Nm.
- Reconnect the connector.
- Reconnect the battery clamp.
- Fill the air conditioning (A/C) system.
