Distance Sensor: Service and Repair
ACC sensor, removing and installing Radar sensor is located behind bumper cover.
Removing ^
Remove front bumper.
^
Remove hex bolts -1-.Tightening torque
8 Nm ^
Remove sensor and disconnect harness connector.
Installing Installation is the reverse of removal.
