Microphone Unit In Front Roof Module






Telephone System

Microphone Unit in Front Roof Module

• Microphone Unit (in front roof module) (R164) consists of a maximum of 3 microphones. Microphone unit (in front roof module) can only be replaced as a complete unit.

- Switch off all electrical consumers.

- Remove the key.

Removing

- Remove the Front Interior Light (W1).

- Unclip harness connector - 2 - from retainer - 1 -.





- Pry the individual microphones - 2 - out of retainer in - direction of arrow -.





Installing

- Install in reverse order.
