Backrest Ventilation

Power Memory Front Seats

Backrest Ventilation





• Rubber guide - 1 - is sewn onto upholstery - 2 -. If rubber guide is malfunctioning, the upholstery must be replaced.

Removing

- Remove seat. Side Trim, Sill Side

- Mount the fixture for seat repair (VAS 6136) on the engine and transmission holder (VAS 6095).

- Attach the front seat to the fixture for seat repair (VAS 6136).

- Remove top backrest cover. Upper Backrest Cover

- Remove bottom backrest cover. Lower Backrest Cover

- Remove connector - 4 -.

- Push cover - 6 - aside.

- Drill out rivets - 5 - (Qty. 2).

- Remove seat ventilation - 3 -.

Installing

- Install seat ventilation - 3 - in reverse order of removal.
