Diagram 121/2 (Tracks 1-14)

IMPORTANT NOTE:
This manufacturer uses "Track" style wiring diagrams.
For information on how to use these diagrams effectively, please refer to Diagram Information and Instructions. Diagram Information and Instructions


Battery, Energy Management Control Module, Battery Interrupt Igniter





ws = white
sw = black
ro = red
br = brown
gn = green
bl = blue
gr = grey
li = lilac
ge = yellow
or = orange
rs = pink

A - Battery

J234 - Airbag Control Module Control Modules Overview

J644 - Energy Management Control Module Control Modules Overview

N253 - Battery Interrupt Igniter Locations

S131 - Safety Fuse 1 Fuse Overview

S132 - Safety Fuse 2 Fuse Overview

S133 - Safety Fuse 3 Fuse Overview

SC15 - Fuse 15 (on fuse panel C) Fuse Overview

SC38 - Fuse 38 (on fuse panel C) Fuse Overview

SC40 - Fuse 40 (on fuse panel C) Fuse Overview

T46b - 46-Pin Connector, black, right CAN separating connector

(3) - Ground strap, engine to body

(18) - Ground Connection (on engine block)

(B272) - Plus Connection (30) (in main wiring harness)

(B299) - Plus Connection 3 (30) (in main wiring harness)

(B304) - Plus Connection 8 (30) (in main wiring harness)

• - CAN-Bus (data wire)

* - In luggage compartment, right rear

Next Diagram 121/3 (Tracks 15-28)
