With VAS5051

Diagnostic Trouble Code (DTC) memory, erasing

Requirements:
- DTC memory scanned.
- All malfunctions corrected.

After DTC scan has been checked:





Display on VAS 5051:
- In selection touch -1- diagnostic function "05 - Delete DTC memory".





Display on VAS 5051:
1 - ^ No display (before deletion)
or
- ^ DTC memory deleted

Note: If the message appears in display field -1-: DTC memory has not been scanned yet the test procedure was not followed exactly. The DTC memory can only be deleted if the DTC memory was scanned previously.

2 - Note: Are you sure you want to do this? Note: Data will be deleted!
- Touch OK" button in display -2-.
- End function "05 - Delete DTC memory" by touching [] button.
- After repair scan DTC memory again.

Note: This deletes DTCs which were stored during repair of the fault, for example by removing harness connectors.

- After scanning and deleting DTC memory, test drive vehicle and scan DTC memory again.
The scan of the DTC memory must display:
"No DTC recognized"
