Rear Bench Seat

Seat Heating Control Module J882

Removing

- Remove the front center armrest.

- Disconnect the connector - 2 -.

- Remove the nut - 3 - and the seat heating control module (J882).

Installing

Install in reverse order of removal.

Installation note: For example tightening specifications, replace components => [ Component location ] Rear Seat Bench Assembly Overview.
