Bluetooth(R) - Call Displays as Active After Ended
SIB 84 13 05Phone, Navigation Systems
May 2007
Technical Service
This Service Information bulletin supersedes S.I. B84 13 05 dated March 2007.
[NEW] designates changes to this revision
SUBJECT
Bluetooth(R) Phone Call May Still be Displayed as Active after the Call has Ended
MODEL
E46 (3 Series) from 9/04 production (325i/iA from 10/04 production) with Premium Package (ZPP) or BMW Assist(TM) (SA 639)
E53 (X5) from 10/04 production with Premium Package (ZPP) or BMW Assisttrade; (SA 639)
E60, E61 (5 Series) from 9/04 production
E63, E64 (6 Series) from 9/04 production
E65, E66 (7 Series) from 3/05 production
E83 (X3) from 9/04 production with Premium Package (ZPP) or BMW Assisttrade; (SA 639)
E85 (Z4) from 10/04 production with Premium Package (ZPP) or BMW Assisttrade; (SA 639)
[NEW] E70 (X5) with Premium Package (ZPP) or BMW Assisttrade; (SA639)
E90, E91, [NEW] E92, E93 (3 Series) with Premium Package (ZPP) or BMW Assist(TM) (SA639)
AFFECTED HANDSET
Motorola RAZR V3
Motorola V330
Motorola V551
Motorola V600
Motorola V710
Motorola E815
SITUATION
The phone call has ended but the communication menu shows the call time counter still counting and the radio remains muted.
CAUSE
After a call has ended, the Bluetooth� phone call may still be displayed as active when:
^ The customer is on an active call with the handset and bonds a handset to a vehicle. Afterwards, the customer tries to hang up the call via the MFL or i-Drive/C1D.
^ The handset battery becomes exhausted during a phone call.
^ The handset drops a call because of poor cellular reception.
^ The customer is on an active call and receives a "Call Waiting" call.
The call has been terminated on the Motorola handset. However, the handset does not send a confirmation message to the vehicle that the call was successfully terminated. Therefore, the call is still shown as active in the vehicle (ghost call).
CORRECTION
Do not replace any parts! This problem is caused by a handset software error. Please create a PuMA case (Info only) documenting the customer's concern. The PuMA case should include the handset model number and the software version installed in the handset.
^ Customer work around procedure: The customer should switch off, and then switch back on, their handset or switch off and back on the Bluetooth function in the vehicle.
^ BMW's solution: BMW will introduce a fix to allow the TCU to terminate the call if the MFL button is pressed a second time. On E65, E66 vehicles, the End Call button on the phone board must be pressed, not the MFL button.
Because the handset did not send the Terminate Call command to the vehicle the TCU will continue to show the call as active in the vehicle (ghost call). Unfortunately, because of Bluetooth� technology limitations, BMW's long term software fix will have an issue. If the customer makes a second call without the Bluetooth� bond being terminated, the new call will be disconnected. This is because the TCU and the handset are in two different modes. If the customer then presses the phone button on the MFL a second time, the handset will connect the call.
For E60, E61, E63, E64, E65, E66 and E90 vehicles, on a customer complaint basis only, refer to the following procedure:
Update the complete vehicle per SI B09 05 01 (Coding, Individualization, Programming) Procedure B using Progman V24.02.01 or higher.
The listed handsets do NOT have a software update available to correct the issue. The customer may want to contact their cellular service provider to notify the provider of the problem with their handsets.
WARRANTY INFORMATION
Covered under the terms of the BMW New Vehicle Limited Warranty.
Defect Code: Refer to KSD
Labor Operation: Refer to KSD
Labor Allowance: Refer to KSD
