Fuse Block: Service and Repair

Description:





Remove or Disconnect
1. Right sound insulator.
2. Two fasteners from Relay/Fuse Center at lower I/P.
3. One fastener from the forward side of the I/P Carrier above Relay/Fuse Center.
4. Disengage cam locks securing harness connectors to Relay/Fuse Center. (Pull down on tabs).
^ There are four cam locks, two are from the bottom and two are from the top.
5. Relay/Fuse Center from I/P.

Install or Connect
1. Align Relay/Fuse Center to lower I/P
2. Secure harness connectors to center and engage cam locks.
3. Fasteners to I/P
4. Right Sound Insulator.
