22. Timing Chain and Sprockets Removal

1. Align the timing marks on the sprockets.





2. Remove the timing chain dampener.





3. Remove the camshaft sprocket bolt.
4. Remove the camshaft sprocket.
5. Remove the timing chain.
6. Remove the crankshaft sprocket.





7. Remove the balance shaft drive gear.
