Oil Pressure Sensor: Service and Repair

Removal Procedure

Notice: Numbers in text correspond to numbered components in image.

1. Raise the vehicle and support.
2. Remove the front splash shield.
3. Remove the electrical connector (2).
4. Remove the sensor (2) from the oil filter adapter (3).

Installation Procedure

1. Install the sensor (2) to the oil filter adapter (3). Tighten the sensor to 12 Nm (106 lb in).
2. Replace the electrical connector (2).
3. Replace the front splash shield.
4. Lower the vehicle.
