Without Air Conditioning
Figure 2 - Air Distribution System Component View:
Figure 12 - Blower Motor Case Replacement:
REMOVE OR DISCONNECT (Figures 2 and 12)
1. Negative battery cable.
2. Electrical connection (91) at the blower motor (54).
3. Blower motor retaining screws (99) (figure 12).
4. Blower motor (54).
INSTALL OR CONNECT
1. Blower motor (54).
2. Screws (99) (figure 12).
^ Tighten-Screws (99) to 2 Nm (18 in. lbs.).
3. Electrical connection (91) to the blower motor (54).
4. Negative battery cable.
