System Check - Compressor Controls
=�JCompressor Controls System Check Table:
Compressor Controls System Check Table^
Complete the
A/C System Check under
A/C System Diagnosis as a guide to normal operation of the entire A/C system and for references to diagnostic tests.
^
Use the System Check Table a guide to normal
A/C compressor operation.
^
Refer to
System Diagnosis when a result is not normal.
Testing and Inspection
