Outside Air Temperature Sensor Replacement




REMOVAL PROCEDURE
1. Remove the radiator grille.
2. Lift the temperature sensor upward in order to remove the temperature sensor.
3. Disconnect the electrical connector.

INSTALLATION PROCEDURE
1. Connect the electrical connector.
2. Install the temperature sensor by sliding the temperature sensor downward.
3. Install the radiator grille.
