Front Door Weatherstrip: Service and Repair

Weatherstrip Replacement - Front Door

Removal Procedure





1. Remove the front side door check pin (2) and position the front side door check (3) away from the door jamb.




2. Gently pry loose the plastic retainers which secure the front side door weatherstrip (5) and remove the weatherstrip from the front side door.



Installation Procedure





1. Install the front side door weatherstrip (5) to the front side door. Ensure that the plastic retainers are fully engaged.




2. Install the front side door check (3) to the door jamb. Secure the check with the pin (2).
