Installation
TAIL LAMP UNIT 1.
Insert the
tail lamp unit into the rear body panel (1) and install the retaining nuts. Tighten
to 2 Nm (± 0,3Nm) (18 in. lbs.).
2.
Connect the harness connector and install the access panel into the rear cargo area interior trim panel.
3.
Connect the negative battery cable.
