Removal
REMOVAL 1.
Remove seat from vehicle.
2.
Remove rear seat cushion side shields.
3.
Remove
seat back.
4.
Remove track assembly.
5.
Disengage J-strap attaching
seat cover from the
seat cushion frame.
6.
Pull cover off of the hog rings.
7.
Cut hog rings attaching
seat cover to
seat cushion pad.
8.
Remove seat cushion cover from
seat cushion.
